Product Information "SkyRC Drift Gyro GD401A"

The SkyRC GD-401A is a compact, high-precision gyro sensor for RC drift cars. It detects deviations in the vehicle's steering and automatically corrects them for more stable handling, smoother counter-steering maneuvers, and greater control in every turn.

A 32-bit processor works in conjunction with a high-precision MEMS gyro to deliver fast, natural responses. Nine preset steering curves for different driving styles and tracks can be selected with a single button – from soft settings for beginners to aggressive curves for professionals. Servo travel can be adjusted within 180° via EPA, and the steering direction can be reversed in 5 seconds with a one-touch reverse function – ideal for various chassis layouts.

The robust CNC-machined aluminum housing (6063) ensures stability and effective heat dissipation. Thanks to its integrated cable and compact design, the GD-401A can be easily integrated into almost any chassis. Besides RWD drift cars, it is also compatible with touring, rally, and short-course models.


The GD-401A is built from a robust CNC-machined aluminum housing (6063) for stability and effective heat dissipation. Thanks to its integrated cable and compact design, the GD-401A can be easily integrated into almost any chassis. In addition to RWD drift cars, it is also compatible with touring, rally, and short-course models.

... Technical Specifications:

Housing Material: 6063 Aluminum, CNC-machined
Processor: 32-bit with MEMS gyro
Input Signal: PWM 50 - 333 Hz
Output Signal: 1520 µs (50 - 333 Hz)
Operating Voltage: 4.8 - 7.4 V
Current Consumption: 20 mA @ 6 V
Steering Curves: 9 preset
Servo Travel (EPA): Adjustable up to 180°
Operating Temperature: -10 °C to 40 °C

Package Contents:

1x SkyRC GD-401A Drift Gyro
1x Instruction Manual
